This project is a step-by-step tutorial that introduces basic concepts of modern CI/CD pipelines by creating a useful end-to-end system that is secure and deploys to a lightweight server being a Raspberry Pi 5 available through a public IP.
Connected applications are expected to encompass availability, scalability, maintainability, impenetrability, testability and reliability amongst a host of other abilities. Traditionally, deployment of these applications was a tedious and manual process prone to a multitude of human errors which could be as simple as the skipping of crucial tests or missing a key security configuration leading to disruptions to users potentially dealing a fatal blow to organizational objectives.
Modern applications are served using complex infrastructures that include cloud paradigms with entire businesses critically dependent upon the smooth deployment and reliable delivery of services. The complex, security-sensitive and sometimes vendor-dependent configuration required to utilize infrastructure-as-a-service makes manual configuration very difficult and cumbersome to reproduce reliably. Infrastructural dependencies required by a server can soon become obsolete requiring reconfiguration and redeployment.
Setups are required to be deployed with slight configuration variations in different environments as per stages of a software development lifecycle. With increasingly stricter security requirements, data isolation may be required with similar services deployed in data centers in individual operative countries. Deployments should be flexible and not cloud-vendor locked and due to financial incentives, may require to near-seamlessly shift to another cloud provider altogether. The repeatability of operations requires spot-on accuracy with very less tolerance for mistakes for ensuring business continuity.
Thus lately, the continuous integration and delivery of applications is treated like a first-class citizen in forward-thinking organizations embracing the DevOps movement.
CI/CD (Continuous Integration / Continuous
Delivery)
The discipline of merging code frequently such that it is automatically
built, tested and deployed in various environments from development to
production such that mostly software served through the Internet is
delivered continuously.
IaC (Infrastructure as Code)
Description of deployed infrastructure in a declarative language to
automatically and precisely replicate steps to be taken for deploying
infrastructure like servers, networks, Kubernetes clusters etc.
CMS (Content Management System)
A software system used to manage the creation and modification of
digital content.
SSH (Secure Socket Shell)
A network protocol used to securely access a Linux machine remotely and
execute commands on it.
UFW (Uncomplicated Firewall)
A frontend for iptables to make netfilter firewall configuration more
user-friendly.
Ansible
An open source IT automation engine that automates provisioning,
configuration management, application deployment, orchestration, and
many other IT processes.
Docker Container Image
A standard, lightweight, standalone, executable package of software that
includes everything needed to run an application as a container at
runtime.
Dockerfile
A text document that contains all the commands a user could call on the
command line to assemble a container image.
Kubernetes (K8s)
An open source system for automating deployment, scaling and management
of containerized applications.
k3s
A highly available, certified Kubernetes distribution designed for
production workloads in resource-constrained servers optimized for
ARM.
Helm
A package manager for Kubernetes that uses charts that are templatized
and shared configuration that make it easy to deploy complex Kubernetes
applications comprising of multiple resources.
Pod
The smallest deployable units of computing comprising of one or more
containers that can be created and managed in Kubernetes.
Terraform
An IaC tool that allows for building, changing and versioning
infrastructure which can include components like compute instances,
storage, and networking; and high level components like DNS entries.
We will create an IaC solution that uses declarative language to create a base for quick and easy deployment of many application servers on a Raspberry Pi 5 (or any hardware for that matter). Don’t worry if you don’t yet understand the terminology here. The goal of this tutorial is to demystify all of it and open a path for further exploration and self-mastery of the topics covered here.
The repositories of the source code for this tutorial are at:
Note that I will assume that you have a Linux-based system or a Mac. For instructions on other OS, please use ChatGPT or other LLM if you don’t feel lucky enough to Google.
I used an Argon
NEO 5 M.2 NVME PCIE Case for Raspberry Pi 5 to keep the Pi cool
under load as it is to be used as a server after all. The Pi is
connected to my home router using an ethernet cable. The latest version
of Raspbian was used which included the X server as I wanted to explore
the capabilities of the Raspberry Pi 5 as a desktop replacement too.
However, I rarely use the Raspberry Pi as such. I ssh into the Pi for
any configuration and even that is happening increasingly rare because
that’s the work of the CI/CD pipeline. You could go with a headless
setup if you so desire with just a bare minimal OS to function as a
server. When running Raspbian from an SSD, I got disk reads of about 865
MB/s using sudo hdparm -t /dev/nvme0n1. We won’t delve into
details on how to go about doing this as there are enough tutorials that
will help you get Raspbian booting from SSD.
Note that you may require to reset your Raspberry Pi to a fresh state multiple times as you go through this tutorial to understand the automated application of configuration you may first attempt manually to understand the underlying concept that needs to be automated.
It is recommended that you change the root password of the Raspberry
Pi with:
sudo su - ; sudo passwd;
You can enable SSH with password login when installing Raspbian or
later with:
sudo systemctl enable ssh
sudo systemctl start ssh
Create an SSH key pair on your local machine (not the Pi) using
ssh-keygen -t ed25519 -C “your_email_addr@domain.com”
You will find the public and private key pair file at ~/.ssh/id_ed25519. There will be two files:
Copy the public key to the Raspberry Pi using ssh as below:
ssh-copy-id -i ~/.ssh/id_ed25519.pub username@<raspberry-pi-ip>
This keypair will be used to perform actions using Ansible or Terraform using our local machine or later to store as GitHub Actions secrets thus allowing the Github actions runner to ssh into the Raspberry Pi to perform actions on our behalf.
You should find out the mac address of your Pi and provide it a static IP address using your home router configuration. You will need a public IP to host services and most ISPs enable this for a fee on request. After you obtain a public IP from your ISP, you should forward ports 22, 80 and 443 to the static IP address of your Raspberry Pi on your LAN. It is recommended that you purchase a domain and setup the following DNS records:
We will be using Ansible for post-OS install provisioning and system configuration of the Raspberry Pi automatically. However, it is important to gain a good understanding of the tasks we wish to automate and thus we will first attempt security hardening of our server manually prior to automating it. We will later automate almost all of the steps below.
We must ensure that only the ports required are enabled on the Raspberry Pi. Initially we would require only port 22 for SSH to be accessible. For this, we will use UFW (Uncomplicated Firewall) that has a simple configuration syntax and it makes managing iptables more user-friendly. Unnecessary Pi ports will most probably not be exposed through the home router port-forwarding but installing a firewall is nevertheless a good practice on any server.
Step 1: Install UFW
sudo apt update
sudo apt install ufw -y
Step 2: Set default policies
Block incoming connections unless they match an explicit rule:
sudo ufw default deny incoming
Allow Pi to initiate outgoing connections:
sudo ufw default allow outgoing
Step 3: Allow TCP traffic on required ports
Port 22 (SSH), 80 (HTTP) & 443 (HTTPS):
sudo ufw allow 22/tcp
sudo ufw allow 80/tcp
sudo ufw allow 442/tcp
Later we can enable another port for calling the API to control the K8s cluster.
Step 4: Enable UFW
sudo ufw enable
This will ask you to confirm if you want to enable as this will disrupt your current ssh session. Since you have allowed ssh, confirm by pressing ‘y’.
Step 5: Check the status of UFW rules
sudo ufw status numbered
Status: active
To Action From
-- ------ ----
[ 1] 22/tcp ALLOW IN Anywhere
[ 2] 80/tcp ALLOW IN Anywhere
[ 3] 443/tcp ALLOW IN Anywhere
[ 4] Anywhere DENY IN Anywhere
[ 5] 22/tcp (v6) ALLOW IN Anywhere (v6)
[ 6] 80/tcp (v6) ALLOW IN Anywhere (v6)
[ 7] 443/tcp (v6) ALLOW IN Anywhere (v6)
[ 8] Anywhere (v6) DENY IN Anywhere (v6)
Optional Configuration:
Optionally for extra security you can restrict ssh access to only a
whitelisted IP address with the below command.
ufw allow from <IP address> to any port 22 proto tcp
However, it will require deletion of the rule added to allow access
from 22 from anywhere with:
ufw delete <rule number>
You an enable logging for blocked traffic.
sudo ufw logging on
sudo ufw logging medium
Logs can be checked with:
sudo journalctl | grep UFW
sudo journalctl -u ufw -n 20
Step 6: Disable other login methods on the Pi
Edit the /etc/ssh/sshd_config file with:
sudo nano /etc/ssh/sshd.config
Ensure these lines are set to ensure that only public key authentication is possible and other login methods including root login is disabled under any circumstances.
PasswordAuthentication no
ChallengeResponseAuthentication no
UsePAM no
PermitRootLogin no
PubkeyAuthentication yes
Step 7: Restart SSH
sudo systemctl restart ssh
We have performed the first steps in preparing your Raspberry Pi manually. Imagine you had a hundred such server machines to configure on an in-prem data center or VMs on a cloud. Here is where Ansible can help us automate configuration and installation of servers wholesale. As an exercise, try to reverse the steps you already performed to understand your success in replicating the processes for automatic configuration in this section. We will create an Ansible pipeline which will automate the manual security configuration you did in section 2.4 and install k3s in later sections. We will first run the automation from our local machine by executing Ansible on the command-line and subsequently we will automate the pipeline to execute as a GitHub Actions runner when changes are done on the pipeline and pushed to your Github repository.
The first concept to grasp is the Ansible inventory file. This contains the inventory of hosts, also called nodes, and their groups which have to be configured. Individual variables can also be defined on the hosts and nodes for flexible automation. The inventory can be statically defined in the file or can be pulled from external sources dynamically. We will only concern ourselves with the static inventory of one Raspberry Pi node that we will configure.
Make an ansible/inventory.yml file with the following contents:
---
raspberrypi:
hosts:
pi:
ansible_host: "{{ lookup('env','PI_HOST') }}"
ansible_user: "{{ lookup('env','PI_USER') }}"
ansible_port: "{{ lookup('env','PI_SSH_PORT') }}"The PI_HOST, PI_USER and PI_SSH_PORT variables can be exported locally if you run the Ansible playbook from your local machine and later added as a secret into GitHub Actions. Use the DNS or IP as the host. For the port, use the default SSH port which is 22 or another if you are using a non-default port and the name of your user on the Raspberry Pi. Ansible will use these variables to ssh into your raspberry Pi and run commands on your behalf.
Credentials will be required for Ansible to ssh into the Raspberry Pi and execute commands and the keypair you generated earlier will be used.
Let’s start making the initial Ansible Playbook. Create a file called ansible/playbooks/setup_pi.yml and add the following content. Note that YAML is very strict in indentation.
--- # Indicates YAML file start
- name: Configure Raspberry Pi # Defines the name of the play
hosts: raspberrypi # Run the tasks on host defined in the inventory
become: true # Run all tasks with sudo
vars: # Lookup PI_HOST from the env and store it in pi_host
pi_host: "{{ lookup('env', 'PI_HOST') }}"
tasks:
- name: Ensure apt is updated
apt: # Update package index and upgrade installed packages
update_cache: yes
upgrade: dist
- name: Ensure UFW is installed
apt: # apt is a module in Ansible
name: ufw # Install ufw using apt if not already installed
state: present
- name: Allow only some ports via UFW
ufw: # Configure ufw
rule: allow
direction: in # Allow incoming port
port: "{{ item }}" # {{ item }} gets replaced with each item
proto: tcp
with_items: # Allows looping through values
- '22'
- '80'
- '443'
- name: Default deny incoming
ufw: # Deny all incoming ports on UFW except the above
rule: deny
direction: in
- name: Enable UFW
ufw: # Note that ufw is a module in Ansible
state: enabled
- name: Setting secure SSH options
lineinfile: # Ensures line matches in a file or replaces
path: /etc/ssh/sshd_config
regexp: "^#?{{ item.option }}" # Match this if changes required
line: "{{ item.option }} {{item.value}}"
create: yes
backup: no # Don’t create backup of the file
loop: # Allows looping through key-value pairs
- { option: "PasswordAuthentication", value: "no" }
- { option: "ChallengeResponseAuthentication", value: "no" }
- { option: "UsePAM", value: "no" }
- { option: "PermitRootLogin", value: "no" }
- { option: "PubkeyAuthentication", value: "yes" }
notify: Restart SSH # Triggers handler to restart SSH if changes made
handlers:
- name: Restart SSH
service:
name: ssh
state: restartedThe steps should be relatively straightforward as it somewhat replicates what you did with the command-line earlier. To help go through our Ansible Playbook block-by-block, I have added comments to the code listing above.
Ansible comes packaged with modules that are units of work. Each task defined typically uses a module. Here we use the following modules: apt, ufw, linefile, service which are part of ansible.builtin module source/collection. You can specify the fully qualified name (FQCN) like ansible.builtin.linefile.
Many Ansible modules check the current state before making unnecessary changes. When a change is made, the task is marked as ‘changed’ otherwise it is ‘ok’. The notify directive in a task triggers a ‘handler’ if the task resulted in a change as illustrated with the ‘Restart SSH’ handler in our playbook.
As an exercise, use the following commands to learn about each module we use with documentation available through the command-line or online. Below are some helpful commands to help you on your quest:
ansible-galaxy collection listansible.doc -lansible.doc -l | grep <name>ansible-doc aptWe can run this Ansible playbook locally from your development machine by exporting the environment variables required. Install Ansible on your local machine as it will help you confirm that your Ansible playbook works and debug when required.
From the root, execute the following commands:
export PI_SSH_PORT=”22”
export PI_HOST="<Pi’s host or IP>"
export PI_USER="<Username on Pi>"
ansible-playbook -i ansible/inventory.yml ansible/playbooks/setup_pi.yml
This should execute the changes on your Raspberry Pi. You can manually undo changes as experiments and see if Ansible reapplies the desired state as per the Playbook.
GitHub Actions allows custom CI/CD workflows to be executed on ‘runners’ when events occur on a code repository. The runner is a (Ubuntu, Windows or MacOS) container image that executes the GitHub workflow job. GitHub is very ‘generous’ and provides free compute resources as GitHub-hosted runners. Come to think of it, if it was not free, I would not use it and you would not be reading this. 2,000 minutes of free runner minutes are provided as part of the free plan and this should suffice for the needs of a learner. If you want more, you can buy paid plans or host runners privately if you prefer.
GitHub Actions also offers such features as secure secret management
that we will use to store credentials and other variables to be injected
at runtime for use in our workflows.
The private key should be accessible by the pipeline. For this, we
create a secret in GitHub Actions. In your repo, go to
Settings->Security->Actions->New repository secret and create a
secret called SSH_PRIVATE_KEY. Copy the text contents of
~/.ssh/
Create a repo on Github for the CI/CD IaC pipeline. Commit the Ansible playbook there in the following directory structure:
├── README.html
└── ansible
├── inventory.yml
└── playbooks
└── setup_pi.ymlWe will listen to the commit event on the prod folder on the base infra repository which will trigger a workflow to run the Ansible playbook inside a GitHub Actions runner. To start,
Then we will add environment variables that will be injected when the runner is executing the pipeline. In the GitHub repository web interface, click the settings icon and then expand “Secrets and variables” and enter “Actions”. We will add 1 variable and 3 secrets currently.
Let’s create a github workflow to run this Ansible playbook. Create a file .github/workflows/ci-cd.yml. Add the following:
name: CI/CD for Raspberry Pi
on:
push:
branches: [ "main" ]
jobs:
build-deploy:
runs-on: ubuntu-latest
env:
PI_HOST: ${{ vars.PI_HOST }}
PI_USER: ${{ secrets.PI_USER }}
PI_SSH_PORT: ${{ secrets.PI_SSH_PORT }}
steps:
- name: Check out repo
uses: actions/checkout@v4
- name: Setup SSH
uses: webfactory/ssh-agent@v0.9.0
with:
ssh-private-key: ${{ secrets.SSH_PRIVATE_KEY }}
- name: Add Pi host key to known_hosts
run: |
mkdir -p ~/.ssh
ssh-keyscan -p $PI_SSH_PORT $PI_HOST >> ~/.ssh/known_hosts
chmod 600 ~/.ssh/known_hosts
- name: Install Ansible
run: |
sudo apt-get update
sudo apt-get install ansible -y
- name: Run Ansible Playbook
run: |
ansible-playbook \
-i ansible/inventory.yml \
ansible/playbooks/setup_pi.ymlExplanation of the pipeline is as follows:
Commit this to your repo to the default (main) branch and this should
trigger the build-deploy job. You can also ssh into the Raspberry Pi
before the job executes and run commands like
sudo ufw reset to verify that the pipeline worked. You can
validate the successful execution with
sudo ufw status numbered on the Pi.
To watch your workflow runs, click on the Actions tab in your repository and it should show a job ran for your last commit because of the presence of the file .github/workflows/ci-cd.yml. You can click the job and explore the run in depth.
The aim was to create a very simple content management system for simple articles with links and images. I realized that markdown was enough for my purposes and thus found that the utility Pandoc, a universal document converter can convert markdown into HTML. This was the first article I published using this method. I actually am writing this article on Google Drive as a Google Doc which allows me to download the document as a markdown (md) file from which I copy-paste the relevant portions. I use VSCode to fine-tune the markdown produced and push it to the GitHub repository which triggers the CI/CD pipeline executed in a GitHub Actions runner. The pipeline executes a script that runs Pandoc and converts each md file into HTML and then copies the HTML and images into a NGINX docker image and then publishes the image to the Docker Hub container image library.
Markdown is a lightweight markup language for creating formatted text using a plain text editor. Most developers come across markdown when writing README.html files which are published as default as HTML on source code repository services. The markdown format was rebranded as CommonMark and adapted as a standard with RFC 7763 introducing a MIME type ‘text/markdown’.
Common formatting options are as follows:
To look at how this webpage was made, head to the md file in the GitHub repo at https://github.com/fareed1983/profile/blob/main/site/homepi-cicd-pipeline.html and view the “raw” version.
Virtualization was the answer to under-utilization of hardware resources by packing more server loads shared on the same physical server. In the early 2000s, server virtualization used hypervisors that emulated the entire machine with each guest OS running its own kernel. This allowed for strong isolation mixing different OSes. However, these virtual machines took a long time to boot up and consumed a lot of memory and CPU resources.
With microservices taking center stage, the need arose for a lot more isolated servers that were continuously delivered and code changes were expected to reach production within minutes. Only an application and the user space libraries started being isolated while the underlying host kernel was shared. Docker was released in 2013 and soon instances of servers could be spawned consuming only a few megabytes of memory in milliseconds.
A Docker image is a template which can be executed running a container. The steps required to build the image are described in a Dockerfile. Each instruction in the Dockerfile (FROM, COPY, RUN etc.) creates a layer that are cached which optimizes the image building and storage process.
Images are generally published on public or private image registries. An image built locally or in a runner as part of a CI/CD pipeline can be published and then distributed to any host that runs Docker or a container orchestration platform like Kubernetes as part of deployment. One such popular registry is Docker Hub which also publishes trusted base images.
Each image is built with a base image which is specified by the FROM instruction. Base images can be chosen based on the OS required, compatibility to technology and frameworks of the application, startup time, security requirements, storage space, reputation and updates and a host of other factors. Some popular official Docker base images include Alpine (lightweight essential Linux), Ubuntu, Python, Node, GoLang, Postgres, Redis etc.
Other instructions are used to copy files into the image (ADD & COPY), add environment variables (ENV), expose ports of the application (EXPOSE), mount volumes for persistent storage (VOLUME), set default executable (ENTRYPOINT), specify default arguments (CMD) etc. Each instruction creates a layer that is cached.
The docker CLI allows for building and testing images locally or publishing them to Docker Hub or any image registry.
The profile web application source repository is hosted at github.com/fareed1983/profile. The application directory structure is as follows.
├── .github
│ └── workflows
│ └── publish.yml
├── .gitignore
├── Dockerfile
├── output
│ ├── homepi-cicd-pipeline.html
│ ├── images
│ │ ├── ci-cd-raspberry-pi-terraform-kubernetes.jpg
│ │ └── linkedin-logo.svg
│ └── index.html
├── README.html
├── scripts
│ └── convert.sh
└── site
├── homepi-cicd-pipeline.html
├── images
│ ├── ci-cd-raspberry-pi-terraform-kubernetes.jpg
│ └── linkedin-logo.svg
└── index.htmlThe site folder contains the md files that are converted into html and outputted in the output folder when scripts/convert.sh is run. The Pandoc document converter runs from within convert.sh which also copies the images. Let’s look at the very simple Dockerfile which has instructions to build the image.
FROM nginx:alpine
WORKDIR /app
RUN apk add --no-cache pandoc bash
COPY . /app
RUN chmod +x /app/scripts/convert.sh && /app/scripts/convert.sh
RUN mv /app/output/* /usr/share/nginx/html/
EXPOSE 80
CMD ["nginx", "-g", "daemon off;"]
NGINX is an HTTP web server, reverse proxy, content cache, load balancer, TCP/UDP proxy server, and mail proxy server. We will only be using the web server part functionality of NGINX to serve our static profile web-pages. For this, we start our image with Docker Hub’s official NGINX Alpine base image with the FROM instruction.
We specify the WORKDIR to /app is just a scratchpad for us which is created in the image and becomes our working directory.
We use RUN to install Pandoc but not cache it and not get stored in the layer as it will not be used at run-time and this keeps the image size small.
COPY . /app copies the entire project directory on the host into /app in the image.
Then we change the permissions of the convert.sh script to be executable and execute it. This converts all md files into html in the output folder and copies the images too.
The output folder is then moved to a location that NGINX uses by default to serve static websites from.
We then expose port 80 so that the container can listen for HTTP connections when the users and/or orchestrators execute the container.
Finally we specify the command to execute which is nginx in our case which launches the NGINX server in the foreground.
You can now build the container locally (after installing docker)
with:
docker build -t fareed83/profile-site:latest -f Dockerfile .
Here ‘fareed83’ is the namespace required by Docker Hub which is my username, ‘profile-site’ is the repository name inside the namespace and ‘latest’ is the default tag name which means that this is the ‘most recent’ image of this repository.
You can list the local images locally as follows:
docker images
You can run the the local image as follows:
docker run --rm -it -p 80:80 fareed83/profile-site:latest
The profile website should now be served on your browser at port 80 (http://localhost:80). You can verify this and pat yourself on the back for your newfound knowledge.
You can remove the image:
docker rmi fareed83/profile-site:latest
At this point, you should create a Docker Hub account if you don’t already have one and create a repository called profile-site. If you want to change the name, also change the name of the image you will be creating.You will need to create a personal access token to use with the CLI from ‘Account Settings’. You can now push images to your Docker Hub repository that you can keep private or publish publicly.
To push the image to Docker Hub, first login and then push as
follows:
Push image from local:
docker login -u "<Docker Hub username>" -p "<personal access token>"
docker push <Docker Hub username>/profile-site:latest
You can now delete the image locally and pull it again from the image
repository:
docker pull <Docker Hub username>/profile-site:latest
We use Github Actions again to automate the building (conversion from md to HTML) and publishing (to Docker Hub) of our application image (the profile-site). This is triggered whenever we update the content on our Github repository. This image will later be picked up by a container orchestrator (K8s in our case). You will need to create two secrets in the Github repository named DOCKERHUB_USERNAME and DOCKERHUB_PASSWORD with your respective values.
Let’s look at our Github Actions workflow.
name: Build Website and Push Docker Image
on:
push:
branches:
- main
jobs:
build-and-push:
runs-on: ubuntu-latest
steps:
- name: Checkout repository
uses: actions/checkout@v4
- name: Set up Docker Buildx
uses: docker/setup-buildx-action@v3
- name: Login to DockerHub
uses: docker/login-action@v3
with:
username: ${{ secrets.DOCKERHUB_USERNAME }}
password: ${{ secrets.DOCKERHUB_PASSWORD }}
- name: Build and push Docker image (multi-arch)
uses: docker/build-push-action@v5
with:
context: .
file: Dockerfile
push: true
tags: fareed83/profile-site:latest
platforms: linux/amd64,linux/arm64Steps of the workflow:
docker build we can use
docker buildx build -t fareed83/profile-site:latest -f Dockerfile --platform linux/amd64,linux/arm64 .
But here our purpose is CI/CD automation.We are now ready to let the orchestration begin!
We can manage a few docker containers easily running applications on servers. However, when hundreds of containers are to be managed throughout their lifecycle, things can get very complicated without the use of automation. As per RedHat, “Container orchestration is the process of automating the deployment, management, scaling and networking of containers throughout their lifecycle, making it possible to deploy software consistently across many different environments at scale”.
The most common container orchestration platform is Kuberenetes (K8s) which is used in self-hosted servers and also supported by various cloud providers natively. Features include service discovery, load balancing, storage management, automated rollouts, rollbacks, container sizing, secret management, configuration management, scaling etc.
K8s comprises a set of independent composable control processes that continuously drive the current state of infrastructure towards a desired state. K8s is deployed as a cluster of a controller plaine plus a set of worker nodes that run containerised applications. In the Raspberry Pi, we will be using K3s which is a bare minimal K8s distribution that can bundle the control plane and worker node into a single-node cluster. The K8s control plane hosts an API server that is exposed to users and other parts of the cluster. K8s provides a kubectl CLI that enables interaction and management of clusters.
K8s resources are described in YAML files which are executed with
kubectl apply -f config-file.yaml which would then create
and/or update components as per the configuration supplied. Files
contain metadata that contains labels and specification that contains
selectors.
Node
These are machines, physical or virtual, that are interconnected and
coordinated as part of a K8s cluster. They can either be the control
plane or workers that contain the pods. Use the command
kubectl get nodes to list all the nodes on a cluster.
Namespaces
They provide a means of isolating groups of resources within a single
cluster and provide a scope for names. Names of resources must be unique
within a namespace. Use the command kubectl get namespaces
to list all the namespaces of a cluster.
Pods
The smallest deployable units of computing in K8s comprising of one or
more containers that can be created and managed in Kubernetes. Pods are
processes. Generally, pods have single containers. However when multiple
containers are run in the same pod, they share resources like the same
network namespace and storage volumes. Generally auxiliary containers
are bundled to a main application in a pod for which logging and
monitoring are good examples of. Each pod in a cluster gets its own
unique cluster-wide IP address. Processes running in different
containers in the same pod can communicate with each other over
localhost. Use the command kubectl
get pods -n <namespace> to list all the pods in a
namespace.
Services
They are a logical set of pods and a policy by which to access them.
They provide a stable and consistent IP address and DNS name even if
pods containing an application are added or removed. Services can be
used to distribute network traffic across multiple pods for load
balancing. A service can be exposed to the public internet using an
ingress or a gateway. There are several service types:
Deployments
A deployment manages a replicated set (ReplicaSet) of pods to run an
application workload, usually stateless. Deployments help to scale
replica pods, enable rollout or rollbacks across replica pods.
StatefulSets
Deployments manage stateless applications while StatefulSets manage
applications that require persistent storage, like database instances.
Keep in mind that the general practice is to host clustered databases
outside the K8s cluster.
Volumes
Allows pods that require data persistence to access and share data
persistently via the filesystem. Data stored in volumes persists across
container restarts. Volumes are mounted at specified paths within the
container file system.
PersistantVolumes
PVs are cluster resources that have a lifecycle independent from any
individual pod that uses the PV. A PV has to be requested by pods
through a PersistentVolumeClaim (PVC). A PVC should be in the same
namespace as the pod claiming it.
Ingress
Ingress
allows making HTTP/s services available using a protocol-aware
configuration mechanism that understands concepts like URIs, hostnames,
paths etc. Ingress is a level-7 proxy server or load balancer that
routes HTTP/s requests to services. It can funnel multiple virtual hosts
and paths through one external address and then routes them services
internally. It also terminates TLS such that pods only need to handle
HTTP requests without encryption. Other optional utilities are rate
limiting, firewall, authentication etc. There are ingress controllers
available for Apache, Traefik, nginx, AWS etc. We will be using the
nginx ingress controller because it is widely used, lightweight, mature
and performant.
CRDs
Custom Resource Definitions (CRD) allows extension of the K8s API by
defining custom resource types. It is a YAML object that extends the K8s
API allowing for the management of new types of objects beyond the
defaults like pods and services. After registration of custom resources,
instances of the new type of resource can be created, read, updated and
deleted.
ConfigMap
Are consumed by pods as environment variables, command-line arguments or
configuration files and are stored as key-value pairs. They allow
decoupling of environment-specific configuration from container
images.
Secrets
Are similar to ConfigMaps but are used to store sensitive values like
password, tokens, keys etc.
Helm
Helm is a templating engine that acts as
a package manager for Kubernetes allowing for easier configuration of a
common set of resources for a given use-case. There are standard bundles
published in public or private repositories which act as reusable
recipes for infrastructure deployment eliminating the need of
configuring complex but widely used deployment patterns from scratch.
Helm uses charts to describe how to run individual applications and
services on Kubernetes. Without Helm, Kubernetes YAML files contain
hard-coded configuration values for such resources as ports, number of
replicas etc. Also, for each application, multiple YAML files have to be
updated without Helm. Helm introduces a templating system that takes
values from a YAML file that it applies to charts.
K3s is a CNCF-conformant Kubernetes distribution which means that it implements the specified APIs that are standardized to manage a cluster. Install K3s in the setup_pi.yml Ansible playbook as follows. Note that the default ingress controller in K3s is Traefik which we intend to replace with NGNIX. Add the following to the Ansible playbook before the handlers section.
- name: Enable cgroup memory in cmdline.txt
lineinfile:
path: /boot/firmware/cmdline.txt
# This regex captures the entire line as group 1
# The 'line' puts cgroup_memory=1 cgroup_enable=memory at the end of that line
regexp: '^(.*)$'
line: '\1 cgroup_memory=1 cgroup_enable=memory'
backrefs: yes
when: "'cgroup_memory=1 cgroup_enable=memory' not in cmdline_content.stdout"
- name: Check if K3s is installed
stat:
path: /usr/local/bin/k3s
register: k3s_bin
- name: Install K3s
shell: curl -sfL https://get.k3s.io | INSTALL_K3S_EXEC="--disable traefik --tls-san {{ pi_host }}" sh -
# We disable trafik as the default ingress controller
when: not k3s_bin.stat.exists
- name: Fetch K3s kubeconfig from Pi
fetch:
src: /etc/rancher/k3s/k3s.yaml
dest: ../../terraform/k3s.yaml
flat: yes
become: yesIn the above,
The data in the k3s.yaml should be kept secret and not shared. We will pull this file into the runner and replace the IP address with the domain name of our Raspberry Pi. Also, we will have to allow the port 6443 in UFW and also forward the port from our router. Communication on this port will be secure because it uses a client-certificate and the client-key-data which is a private key to authenticate the user who can act as the administrator of the cluster. The certificate-authority-data will be used to verify the server and encrypt data in transit with TLS.
We also add the below to the GitHub Actions workflow:
- name: Update server IP in kubeconfig and set path
run: |
sed -i "s|127.0.0.1|$PI_HOST|g" ./terraform/k3s.yaml
echo "KUBE_CONFIG_PATH=$(pwd)/terraform/k3s.yaml" >> $GITHUB_ENVWe do this to change the localhost IP to the provided PI host. Also we set the environment variable required to reference the right K3s configuration for remote management.
After the GitHub Actions workflow is run on merge to the main branch,
use sudo kubectl get pods -n kube-system on the Raspberry
Pi to get an output like the below:
NAME READY STATUS RESTARTS AGE
coredns-ccb96694c-cbzzt 1/1 Running 0 110s
local-path-provisioner-5cf85fd84d-mgmtr 1/1 Running 0 110s
metrics-server-5985cbc9d7-pkh2d 1/1 Running 0 110s
The first part of the command, “kubectl get pods” gets all pods running on the Kubernetes cluster. As no services are deployed, it will not return anything. Adding “-n kube-system” allows the listing of pods running in the kube-system namespace which are core system services. A pod can have multiple containers. The second row, “READY” means that 1 pod out of 1 in the container is running correctly. The other columns are self-explanatory.
To get somewhat of a better grasp on how things really work under the hood, we can host the website using K3s installed on the Raspberry PI by using manual commands on the CLI to better understand the deployment automated by Terraform. We leave it as an exercise to the reader to manually configure the web application using the kubectl command-line based on the automated Terraform IaC pipeline described below.
Our infrastructure application stack will consist of the following resources:
| Layer | Component/Resource (Kind, Name, Namespace) | Purpose |
|---|---|---|
| Edge and TLS | NGINX Ingress Controller (installed with Helm) helm_release.nginx_ingress, ns ingress-nginx | Cluster-wide L7 proxy terminating TLS & routing HTTP to services |
| Service created by the chart (LoadBalancer) | Exposes ingress controller on a public IP | |
| Ingress (profile-site-ingress, ns default) | Declares host-based and path-based rules and forces HTTPs | |
| Certificate Management | cert-manager (installed with Helm) Helm_release.cert_manager, ns cert-manager | CRDs and controllers to issue and renew X.509 certificates for TLS |
| Clusterissuer letsencrypt-prod, cluster-scoped | Configuration for Let’s Encrypt that is referenced by ingress | |
| Certificate Profile-site-tls, ns default | cert-manager automatically requests it and stores key+cert in a secret | |
| Application Workload | Deployment Profile-site, ns default | Manages the profile-site pod/s and keeps them running |
| Pod template Inside Deployment | Container running fareed83/profile:latest image and mounts an volume for Nginx cache | |
| ReplicaSet / Pods Managed by Deployment | We have only one running replica created during rollouts | |
| Networking inside cluster | Service Profile-site-service, ClusterIP | Ingress forwards requests to this IP address and used for load-balancing |
| Storage (ephemeral) | Volume emptyDir called nginx-cache | /var/cache/nginx is mounted in container |
You will realize that the K8s architecture required to run a fairly complex application stack can get unwieldy if manually configured on scale. Thus, we will automate our K8s infrastructure deployment using Terraform.
Terraform is an infrastructure-as-a-code tool created by HashiCorp which allows the definition of data center infrastructure in a human readable declarative configuration language known as HCL. With terraform, consistent workflow can be used to provision and manage infrastructure throughout its lifecycle. You can apply the same config multiple times and get the same result and manage infrastructure changes via Git. Terraform makes infrastructure deployments predictable, auditable and automated.
Terraform creates and manages resources on cloud platforms and other services through their application programming interfaces. For example, it uses the K8s API to manage a K8s compliant cluster and the K8s resources can be declared in HCL like we will be doing in the final part of our project.
Providers
Are plugins distributed separately from Terraform that provide
capabilities to interface with APIs of cloud platforms or services. Some
popular ones are providers for AWS, GCP, Azure
and ones we will be using - Kubernetes
and Helm.
There are also providers for utilities like random
number generation, file
archive management, time
management etc. For browsing through the list of official providers
and their documentation, visit the Terraform Registry. Providers
are declared in the required_providers block and installed when
terraform init is run. Each resource type is implemented by
a provider.
Resources
Defined in resource blocks in the Terraform configuration, they are
infrastructure objects representing virtual networks, compute instances
of higher-level components like DNS records. A resource block declares a
resource of a specific type and a specific local name which can be used
to refer to the resource in the same module. A resource type specifies
the type of infrastructure object it manages and the arguments and
attributes the resource supports. To understand resources of a
particular provider, refer to the Terraform Registry. When resource
blocks are modified HCL files and terraform plan is run,
Terraform will first calculate the differences in the current state to
the desired state in the HCL files and apply the changes at the next
terraform apply. For example, if a resource block is added,
Terraform will provision the resource in the infrastructure and if a
block is deleted, the corresponding provisioned resource will be
deleted.
Data Sources
Allow Terraform to use information defined outside of Terraform by
another separate Terraform configuration, or modified by functions. They
are read-only views to fetch or query things that already exist or are
managed outside Terraform. In our first example, we use the Kubernetes
Namespace to retrieve the UUID of the K8s cluster we installed and
output it as a variable.
Modules
Containers for multiple resources that are used together to fulfill a
purpose like setting up a K8s cluster. A collection of .tf files make up
a module and are kept together in a directory. Modules help organize
reuse of Terraform code.
State
Used to keep track of the current state of resources in the real-world
to understand which changes are required to match the current state of
deployed infrastructure with the desired state as per configuration
files. It is recommended to store state in a remote shared backend and
not in individual workstations to avoid drift and conflicts in between
teams. We use Terraform.io to save the state file.
Variable
Terraform has input and output variables. Input variables serve as
parameters for a Terraform module which allows customizing behaviour.
Output variables return values for a Terraform module.
Providers we will be using and the resources they will create are as follows:
The following changes are required in the GitHub Actions workflow to execute the Terraform automation after the Ansible Playbook is run. We install Terraform and then init, plan and apply the configuration to our K8s cluster. Add the following to the GitHub Actions workflow under where we edit the k3s.config file.
- name: Install Terraform
uses: hashicorp/setup-terraform@v3
- name: Terraform Init
working-directory: ./terraform
run: terraform init
- name: Terraform Plan
working-directory: ./terraform
run: terraform plan
- name: Terraform Apply
working-directory: ./terraform
run: terraform apply -auto-approveFor storing the state of our Terraform pipeline, we will use Terraform Cloud. Create an account on Terraform Cloud and make a new organization and create a project in the organization. Create a new CLI-driven workflow as we are using GitHub Actions to fully run our CI/CD pipeline. We will be running terraform init/plan/apply from GitHub Actions rather than from Terraform Cloud.
Add the following to terraform/providers.tf to initialize the state store and providers.
terraform {
cloud {
hostname = "app.terraform.io"
organization = "<name of the organization created in terraform.io>"
workspaces {
name = "<name of the workspace created in terraform.io>"
}
}
required_providers {
kubernetes = {
source = "hashicorp/kubernetes"
version = "~> 2.35"
}
helm = {
source = "hashicorp/helm"
version = "~> 2.17"
}
kubectl = {
source = "gavinbunney/kubectl"
version = ">= 1.19.0"
}
time = {
source = "hashicorp/time"
version = "~> 0.9"
}
}
}Add the required_providers section above to declare which providers
your configuration depends upon and their download locations along with
the version numbers that need to be enforced. When you run
terraform init these providers will be downloaded and
installed from the Terraform Registry.
Go to Terraform Cloud settings and generate a Terraform team token. Do not commit this token in your code. Instead, store the token as a GitHub Actions secret named TERRAFORM_CLOUD_TOKEN. We will reference this token in our GitHub actions workflow YAML to insert it into the runner for Terraform to use as an environment variable called TF_TOKEN_app_terraform_io when initializing.
Add to env section of the Ansible Playbook:
TF_TOKEN_app_terraform_io: ${{ secrets.TERRAFORM_CLOUD_TOKEN }}
Create a file called test_connection.tf with the following contents :
# 1) Tell Terraform how to find your K3s kubeconfig
# Adjust the path to wherever you placed k3s.yaml after Ansible fetch.
provider "kubernetes" {
config_path = "${path.module}/k3s.yaml"
}
# 2) Use a data source to read the "kube-system" namespace
data "kubernetes_namespace" "kube_system" {
metadata {
name = "kube-system"
}
}
# 3) Output the namespace UID so we can confirm Terraform actually read it.
output "kube_system_uid" {
value = data.kubernetes_namespace.kube_system.metadata.0.uid
description = "Unique ID of the kube-system namespace."
}Run Terraform From Local Machine
To run Terraform from the local machine, first export the following variables:
export PI_SSH_PORT=”<Your Pi SSH port>”
export PI_HOST="<Your Pi Hostname>"
export PI_USER="<Your Pi Username>"
export TF_TOKEN_app_terraform_io="<Your Terraform Token>"
export KUBE_CONFIG_PATH=./k3s.yamlThen run:
terraform init
terraform plan
terraform apply
Test out configuration so far locally. You should see the executed
plan on Terraform Cloud. After this pipeline is applied successfully,
Terraform Cloud will reflect the output and you can verify if the
kube_system_uid is proper from Terraform Cloud running the below
command:
kubectl get namespace kube-system -o json
Run Terraform With GitHub Actions
Since you have added the above commands to the GitHub Actions pipeline, they will be executed when you push your code to your GitHub repository.
Create a file called profile.tf and add the following:
variable "domain" {
type = string
default = "fareed.digital"
}
variable "profile_app_image" {
type = string
default = "fareed83/profile-site:latest"
}
# Deploy NGINX Ingress Controller
resource "helm_release" "nginx_ingress" {
name = "nginx-ingress"
repository = "https://kubernetes.github.io/ingress-nginx"
chart = "ingress-nginx"
namespace = "ingress-nginx"
create_namespace = true
set {
name = "controller.service.type"
value = "LoadBalancer"
}
set {
name = "controller.ingressClassResource.default"
value = "true"
}
}
resource "helm_release" "cert_manager" {
name = "cert-manager"
repository = "https://charts.jetstack.io"
chart = "cert-manager"
namespace = "cert-manager"
create_namespace = true
version = "v1.17.2"
set {
name = "installCRDs"
value = "true"
}
}
resource "time_sleep" "wait_for_cert_manager_crds" {
depends_on = [helm_release.cert_manager]
create_duration = "30s"
}
locals {
clusterissuer = "clusterissuer.yaml"
}
# Create clusterissuer for nginx YAML file
data "kubectl_file_documents" "clusterissuer" {
content = file(local.clusterissuer)
}
resource "kubectl_manifest" "clusterissuer" {
for_each = data.kubectl_file_documents.clusterissuer.manifests
yaml_body = each.value
depends_on = [
data.kubectl_file_documents.clusterissuer,
time_sleep.wait_for_cert_manager_crds // Wait until CRDs are established
]
}
# Deploy the Web App (simplified, without read_only_root_filesystem)
resource "kubernetes_deployment" "web_app" {
metadata {
name = "profile-site"
namespace = "default"
labels = {
app = "profile-site"
}
}
spec {
replicas = 1
selector {
match_labels = {
app = "profile-site"
}
}
template {
metadata {
labels = {
app = "profile-site"
}
}
spec {
# Declare the volume (emptyDir is writable by default)
volume {
name = "nginx-cache"
empty_dir {}
}
# Set pod-level security with fsGroup so volumes are group-owned by 101.
security_context {
fs_group = 101
}
container {
name = "profile-site"
image = var.profile_app_image
image_pull_policy = "Always"
# Mount the volume where Nginx can write caches/temp files.
volume_mount {
name = "nginx-cache"
mount_path = "/var/cache/nginx"
}
port {
container_port = 80
}
resources {
requests = {
cpu = "100m"
memory = "256Mi"
}
limits = {
cpu = "200m"
memory = "256Mi"
}
}
security_context {
allow_privilege_escalation = false
# Note: Removing read_only_root_filesystem ensures the container filesystem is writable.
# Instead of making the entire filesystem read-only, we allow writes so that chown operations can succeed.
capabilities {
drop = ["ALL"]
add = ["CHOWN", "SETGID", "SETUID"]
}
}
liveness_probe {
http_get {
path = "/"
port = 80
}
initial_delay_seconds = 5
period_seconds = 10
}
}
}
}
}
}
# Create a Service for the Web App
resource "kubernetes_service" "web_service" {
metadata {
name = "profile-site-service"
namespace = "default"
}
spec {
selector = {
app = kubernetes_deployment.web_app.metadata[0].labels.app
}
port {
protocol = "TCP"
port = 80
target_port = 80
}
type = "ClusterIP"
}
}
# Ingress Resource for HTTPS with Redirect
resource "kubernetes_ingress_v1" "web_ingress" {
depends_on = [
helm_release.nginx_ingress,
helm_release.cert_manager,
# kubernetes_manifest.letsencrypt_issuer
kubectl_manifest.clusterissuer
]
metadata {
name = "profile-site-ingress"
namespace = "default"
annotations = {
"cert-manager.io/cluster-issuer" = "letsencrypt-prod"
"nginx.ingress.kubernetes.io/force-ssl-redirect" = "true"
}
}
spec {
rule {
host = var.domain
http {
path {
path = "/"
path_type = "Prefix"
backend {
service {
name = kubernetes_service.web_service.metadata[0].name
port {
number = 80
}
}
}
}
}
}
tls {
secret_name = "profile-site-tls"
hosts = [var.domain]
}
}
}In addition, the below file (clusterissuer.yaml) is required for configuring the certificate issuer that allows communication with the Let’s Encrypt production ACME endpoint. It is used to register an ACME account and store the account key in a K8s secret called letsencrypt. It solves HTTP-01 challenges through NGINX ingress controller to install the certificate.
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
name: letsencrypt-prod
spec:
acme:
server: https://acme-v02.api.letsencrypt.org/directory
email: {{ your email address }}
privateKeySecretRef:
name: letsencrypt
solvers:
- http01:
ingress:
class: nginx
podTemplate:
spec:
nodeSelector:
"kubernetes.io/os": linuxFollowing is the explanation of the Terraform configuration:
That was quite a handful! I hope this helped you understand the complexity and nuances of modern CI/CD and IaC workflows. I will continue to update this article as I get more insights and clarity on how the setup operates and evolve this already-endless article. So, check back again.
